LAUNCH X431 PRO5 PRO 5 Car Diagnostic Tools Automotive Tool Full System OBD2 Scanner Intelligent Diagnosis Tool
Shipping& Warranty About Our X431 PRO5:
One Year Warranty and Lifetime Technical Support.
100% Genuine Launch Tool, Global Version, No IP Limited.
Launch X431 PRO5 Highlights:
1. With 2 Years Free Update Online.
2. Upgraded from LAUNCH X431 V+/PRO3/PROS V1.0/TURBO/Throttle – A rich array of future-proof functions for productive works: 1) Smartlink2.0, J2534 ECU Programming, Intelligent AutoVIN & AutoScan, Active Tests, All System Diagnostics, VAG Guided Function, FCA AutoAuth Access, etc.; 2) advanced Online ECU Coding & Adaptations brings more personal settings; 3) 50+ service functions with more frequent updates to support more vehicles.
3. J2534 Reprogramming Tool LAUNCH X431 Smartlink2.0 – 1) Fix the most vehicles’ problems with broad vehicle coverage; meet SAE standards for J2534-1 & -2, CANFD, DOIP and support DC9-36V (Operating voltage) for HD Vehicles (need the extra purchase of HD software, non-16pin HD adaptors); 2) also serves as a wireless VCI.
4. Support J2534 ECU Programming for Mainstream Vehicles: Audi, VW, Seat, Skoda… (Need purchase the programming application from vehicle manufacturer)
5. Advanced Intelligent Diagnostics – AutoVIN & AutoScan accelerates all-systems DTC scans that clock in at an average of < 3 minutes.
6. FCA AutoAuth Access – Bypass SGM in FCA vehicles seamlessly and within seconds; works on 2017 and later Chrysler, Dodge, Jeep, Alfa Romeo, Fiat, etc. *Need AutoAuth subscriptions.
7. VAG Guided Function – Skip the routine procedure of entering the security access code & channel number for VW, Audi, Skoda, Seat vehicles.
8. Great Combination – Android 9.0 OS, 8-core 1.8GHz processor, 3GB RAM & 32GB ROM (128G expandable), 10.1” HD 1920*1200 touchscreen, 8MP rear & 5MP front camera, 7000 mAh battery, etc.
9. Work with Other Extended Modules: ADAS Calibration Toolkit; VSP-600 VideoScope; X431 TPMS TSGUN; BST360 Bluetooth Battery Tester; X-PROG & X-PROG3 Immobilizer.
10. Multilingual Support: English, French, Spanish, Portuguese, Italian, Russian, German, Polish, Dutch, Danish, Greek, Persian , Finnish, Swedish, Chinese, Japanese, Korean
11. NEW! Adds Topology Mapping function since version V7.03.014
12. Supports ADAS Calibration when working with an ADAS Mobile / ADAS PRO.
New Pro5 Smartlink vs Old Pro5
New Pro5 comes with Smartlink C 2.0 passthru VCI which supports dual diagnosis mode: local diagnosis and super remote diagnosis. Smartbox only local diagnosis.
NOTE:
*Online programming is restricted in Spain, and Portugal.
*Super remote diagnosis requires extra license. The license will be available in May or June 2024.
Extended Modules Create Double Achievement
NEW OPTIONAL FUNCTIONS: (Need Buy-Extra)
1) Videoscope Check unseen parts and give you a direct image of the engine, gears, compressors, headers and valves, and body components.
2)X431 i-TPMS Active and relearn TPMS sensors; and program LAUNCH TPMS sensor.
3) X-431 ADAS Mobile/PRO: Operate ADAS calibration to vehicle cameras, LKA system, ACC system, LDW system, and AVM system.
4) X=PROG3 Add, delete, and reprogram keys; rewrite smart keys; replace key ECU.
5) X431 WiFi Printer Print diagnostic data or report for further analyzing and reviewing.
6) BST360 Check the SOH of the on-board battery, functionality of discharge capacity and start-up capacity, etc. Provide a reliable analysis basis for the inspection and maintenance of car batteries.
7) X431 Heavy Duty Module (diagnose gasoline vehicles & 24V Diesel Trucks) https://slt-shop.com/product/heavy-duty-truck-software-license-for-launch-x431-pro5-pad-v-and-pad-vii/
8) EV Diagnostic Kit New Energy Diagnose
Note: You can purchase these extended modules extra, if needed.
2. SmartLink C can be used not only remote diagnosis but also local diagnosis by working with particular LAUNCH intelligent diagnostics
3. Supports more advanced protocols like DoIP, CAN FD, CAN 2.0
4. Publish request and accept offer from Launch Super Remote Diagnosis Reservation Platform
5. Compared with SmartLink 1.0, the SmartLink V2.0 is:
WIFI signal improved
Better heat dissipation
DB15 connector to get more fastened
J2534 ECU Programming – Level up Your Repair Skills & Work Efficiency
As you can see, auto repair shops that need to do high-level repairs, such as replacing or reprogramming ECUs, have to cost dearly for the OEM scanners or J2534 compliant pass-thru tools. Launch odb2 scanner X431 PRO5, combined with the J2534 pass-through device Smart Box 3.0 at no charge, allows the repair shops access and program vehicle computers the same as OEM, without needing the OEM tools.
Highly Cost-Effective with Advanced ECU J2534 Programming, Same as the OEM Programming Tool: this allows you to visit the OEM website and download the OEM software for your application within several minutes through the internet.
What Can J2534 Reprogramming Tool Do?
- Program data to a new module
- Reprogram existing data to the used module
- Repair ECU with data loss
- Upgrade ECU software version
- Compatible with BMW, Benz, Chrysler, Ford, Land Rover, Volvo, Honda, VW, Nissan, Toyota, etc.
Warm Tip: J2534 tool is only compatible with Windows-based computers yet. Available programming operations vary by the test vehicles.
2) You can change the market-specific settings to activate higher-level car functions and disable unneeded features, breaking limitations.
And many more with expanding. Function menus vary by manufacturer, year, and model. Reach us for compatibility check.
See what your car is doing in real time; get car performance, sensor data and more at one glance! This diagnostic scanner presents the live data stream in 3 modes: a. Numbers and lists (default); b. Wave patterns (max. 12 channels in one screen); c. Merged graph (max. 4 data can be merged) for you to quickly identify if the data are in normal conditions, ranges or not.、
Specification:
Tablet Parameters( X-431 PRO5):
CPU: 2.0GHz 4-core
OS: Android 10.0
RAM: 4GB
ROM: 64GB
Display: 10.1 inch
Resolution: 1280*800
Camera: 5MP(Front), 8MP(Rear)
Wi-Fi: 2.4GHz/5GHz （Dual frequency）
Working Temperature: 0~50℃
Size: 274 *190.5 *39.5(mm)
VCI Parameters(SmartLink C):
Processor: Cortex-A7+Cortex-M7
OS: Linux
RAM: 256M
ROM: 8GB
Display: 3.5 inch touch screen
Wi-Fi: 2.4GHz/5GHz dual-band
Diagnostic Communication: WiFi&BT&USB
Test Voltage: DC 9~36V
Working Temperature: 0~50℃
Size: 204*110*45 (mm)
LAUNCH X431 PRO5 Package:
1pc x main unit
1pc x SmartLink C V2.0
1pc x US plug
1pc x EU plug
1pc x UK plug
1pc x OBD adapter
1pc x Type-C cable
1pc x USB-B cable
1pc x Ethernet cable
1pc x for K-20 adapter
1pc x for HA-3 adapter
1pc x for G/V-12 adapter
1pc x for FD-6+1 adapter
1pc x for CR-6 adapter
1pc x for TA-17 adapter
1pc x for TA-22 adapter
1pc x for NN-14+16 adapter
1pc x for MH-12+16 adapter
1pc x for B-20 adapter
1pc x for BZ-38 adapter
1pc x cigarette lighter cable
1pc x for BZ-14 adapter
1pc x battery clamps cable
1pc x box
6pcs x fuses
1pc x quick start guide
1pc x PIN envelope
1pc x user manual
